KIM LIGHTING
Warp9®
Visual Stealth Technology. The standard for slim, low-profile site lighting, WARP9® features visual stealth technology, the antithesis of ornamental design.
Features & Benefits
- TIR Strike Optics
- Aerodynamic design and low EPA for installation in higher wind areas
- Patented low profile luminaire
- Available in Monochromatic Amber, 2700K, 3000K, 3500K, 4000K and 5000K
- 0 - 10V dimming drivers standard
- IP65 optical assembly
Specifications
Lumen Range
1,783 - 14,924
Dimming Protocol
0-10V Dimming
CCT Offering
3000,
4000,
5000
CRI Offering
70,
80,
90
Mounting Options
Arm
Wattage Range
95 - 235.6
Color Offering
BLS - Black Gloss Smooth,
BLT - Black Matte Textured,
DBS - Dark Bronze Gloss Smooth,
DBT- Dark Bronze Matte Textured,
GTT - Graphite Matte Textured,
LGS - Light Grey Gloss Smooth,
LG - Light Grey Matte Textured,
PSS - Platinum Silver Gloss Smooth,
VGT - Verde Green Matte Textured,
WHS - White Gloss Smooth,
WHT - White Matte Textured,
CC – Custom Color
Optics & Distributions
Type I,
Type II,
Type III,
Type IV Wide,
Type V Square Medium,
Right,
Left
Certifications
cUL,
UL 1598
Ratings
TAA (Buy American 52.225-11)
Specifications
| Lumen Range | 1,783 - 14,924 |
| Dimming Protocol | 0-10V Dimming |
| CCT Offering | 3000, 4000, 5000 |
| CRI Offering | 70, 80, 90 |
| Mounting Options | Arm |
| Wattage Range | 95 - 235.6 |
| Color Offering | BLS - Black Gloss Smooth, BLT - Black Matte Textured, DBS - Dark Bronze Gloss Smooth, DBT- Dark Bronze Matte Textured, GTT - Graphite Matte Textured, LGS - Light Grey Gloss Smooth, LG - Light Grey Matte Textured, PSS - Platinum Silver Gloss Smooth, VGT - Verde Green Matte Textured, WHS - White Gloss Smooth, WHT - White Matte Textured, CC – Custom Color |
| Optics & Distributions | Type I, Type II, Type III, Type IV Wide, Type V Square Medium, Right, Left |
| Certifications | cUL, UL 1598 |
| Ratings | TAA (Buy American 52.225-11) |
Product Documents
Spec Sheets
Brochures / Catalogs
Design / BIM Files / 3D Models
Technical Documents
Photometry(0)
Clear Filters| Product Name | Color Temp | CRI | Lumens | LM/W | Watts | Dist. Type | Resources |
|---|---|---|---|---|---|---|---|
| WP9L2-108L-550-3K7-1-BC-CLR | 3000 K | 70 CRI | 11974 lm | 65 | 184.89 W | Type 1 | |
| WP9L2-108L-550-3K7-1-BC-CP | 3000 K | 70 CRI | 10938 lm | 59 | 184.89 W | Type 1 | |
| WP9L2-108L-550-3K7-1-BC | 3000 K | 70 CRI | 14022 lm | 76 | 184.89 W | Type 1 | |
| WP9L2-108L-550-3K7-1-CLR | 3000 K | 70 CRI | 18703 lm | 101 | 184.89 W | Type 1 | |
| WP9L2-108L-550-3K7-1-CP | 3000 K | 70 CRI | 17085 lm | 92 | 184.89 W | Type 1 | |
| WP9L2-108L-550-3K7-1 | 3000 K | 70 CRI | 21901 lm | 118 | 184.89 W | Type 1 | |
| WP9L2-108L-550-3K7-2-BC-CLR | 3000 K | 70 CRI | 11181 lm | 60 | 184.89 W | Type 2 | |
| WP9L2-108L-550-3K7-2-BC-CP | 3000 K | 70 CRI | 10214 lm | 55 | 184.89 W | Type 2 | |
| WP9L2-108L-550-3K7-2-BC | 3000 K | 70 CRI | 13093 lm | 71 | 184.89 W | Type 2 | |
| WP9L2-108L-550-3K7-2-CLR | 3000 K | 70 CRI | 17553 lm | 95 | 184.89 W | Type 2 | |
| WP9L2-108L-550-3K7-2-CP | 3000 K | 70 CRI | 16035 lm | 87 | 184.89 W | Type 2 | |
| WP9L2-108L-550-3K7-2 | 3000 K | 70 CRI | 20555 lm | 111 | 184.89 W | Type 2 | |
| WP9L2-108L-550-3K7-3-BC-CLR | 3000 K | 70 CRI | 10823 lm | 59 | 184.89 W | Type 3 | |
| WP9L2-108L-550-3K7-3-BC-CP | 3000 K | 70 CRI | 9887 lm | 53 | 184.89 W | Type 3 | |
| WP9L2-108L-550-3K7-3-BC | 3000 K | 70 CRI | 12674 lm | 69 | 184.89 W | Type 3 | |
| WP9L2-108L-550-3K7-3-CLR | 3000 K | 70 CRI | 17409 lm | 94 | 184.89 W | Type 3 | |
| WP9L2-108L-550-3K7-3-CP | 3000 K | 70 CRI | 15903 lm | 86 | 184.89 W | Type 3 | |
| WP9L2-108L-550-3K7-3 | 3000 K | 70 CRI | 20386 lm | 110 | 184.89 W | Type 3 | |
| WP9L2-108L-550-3K7-4-BC-CLR | 3000 K | 70 CRI | 13229 lm | 72 | 184.89 W | Type 4 | |
| WP9L2-108L-550-3K7-4-BC-CP | 3000 K | 70 CRI | 12085 lm | 65 | 184.89 W | Type 4 | |
| WP9L2-108L-550-3K7-4-BC | 3000 K | 70 CRI | 15492 lm | 84 | 184.89 W | Type 4 | |
| WP9L2-108L-550-3K7-4-CLR | 3000 K | 70 CRI | 18290 lm | 99 | 184.89 W | Type 4 | |
| WP9L2-108L-550-3K7-4-CP | 3000 K | 70 CRI | 16708 lm | 90 | 184.89 W | Type 4 | |
| WP9L2-108L-550-3K7-4 | 3000 K | 70 CRI | 21418 lm | 116 | 184.89 W | Type 4 | |
| WP9L2-108L-550-3K7-4W-BC-CLR | 3000 K | 70 CRI | 11186 lm | 61 | 184.89 W | Type 4W | |
| WP9L2-108L-550-3K7-4W-BC-CP | 3000 K | 70 CRI | 10218 lm | 55 | 184.89 W | Type 4W | |
| WP9L2-108L-550-3K7-4W-BC | 3000 K | 70 CRI | 13099 lm | 71 | 184.89 W | Type 4W | |
| WP9L2-108L-550-3K7-4W-CLR | 3000 K | 70 CRI | 17439 lm | 94 | 184.89 W | Type 4W | |
| WP9L2-108L-550-3K7-4W-CP | 3000 K | 70 CRI | 15930 lm | 86 | 184.89 W | Type 4W | |
| WP9L2-108L-550-3K7-4W | 3000 K | 70 CRI | 20420 lm | 110 | 184.89 W | Type 4W | |
| WP9L2-108L-550-3K7-5Q-CLR | 3000 K | 70 CRI | 18082 lm | 98 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-3K7-5Q-CP | 3000 K | 70 CRI | 16518 lm | 89 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-3K7-5Q | 3000 K | 70 CRI | 21174 lm | 115 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-3K7-L-CLR | 3000 K | 70 CRI | 17357 lm | 94 | 184.89 W | Type L | |
| WP9L2-108L-550-3K7-L-CP | 3000 K | 70 CRI | 15855 lm | 86 | 184.89 W | Type L | |
| WP9L2-108L-550-3K7-L | 3000 K | 70 CRI | 20325 lm | 110 | 184.89 W | Type L | |
| WP9L2-108L-550-3K7-R-CLR | 3000 K | 70 CRI | 17357 lm | 94 | 184.89 W | Type R | |
| WP9L2-108L-550-3K7-R-CP | 3000 K | 70 CRI | 15856 lm | 86 | 184.89 W | Type R | |
| WP9L2-108L-550-3K7-R | 3000 K | 70 CRI | 20326 lm | 110 | 184.89 W | Type R | |
| WP9L2-108L-550-4K7-1-BC-CLR | 4000 K | 70 CRI | 12426 lm | 67 | 184.89 W | Type 1 | |
| WP9L2-108L-550-4K7-1-BC-CP | 4000 K | 70 CRI | 11351 lm | 61 | 184.89 W | Type 1 | |
| WP9L2-108L-550-4K7-1-BC | 4000 K | 70 CRI | 14551 lm | 79 | 184.89 W | Type 1 | |
| WP9L2-108L-550-4K7-1-CLR | 4000 K | 70 CRI | 19409 lm | 105 | 184.89 W | Type 1 | |
| WP9L2-108L-550-4K7-1-CP | 4000 K | 70 CRI | 17730 lm | 96 | 184.89 W | Type 1 | |
| WP9L2-108L-550-4K7-1 | 4000 K | 70 CRI | 22728 lm | 123 | 184.89 W | Type 1 | |
| WP9L2-108L-550-4K7-2-BC-CLR | 4000 K | 70 CRI | 11603 lm | 63 | 184.89 W | Type 2 | |
| WP9L2-108L-550-4K7-2-BC-CP | 4000 K | 70 CRI | 10599 lm | 57 | 184.89 W | Type 2 | |
| WP9L2-108L-550-4K7-2-BC | 4000 K | 70 CRI | 13587 lm | 73 | 184.89 W | Type 2 | |
| WP9L2-108L-550-4K7-2-CLR | 4000 K | 70 CRI | 18216 lm | 99 | 184.89 W | Type 2 | |
| WP9L2-108L-550-4K7-2-CP | 4000 K | 70 CRI | 16640 lm | 90 | 184.89 W | Type 2 | |
| WP9L2-108L-550-4K7-2 | 4000 K | 70 CRI | 21331 lm | 115 | 184.89 W | Type 2 | |
| WP9L2-108L-550-4K7-3-BC-CLR | 4000 K | 70 CRI | 11232 lm | 61 | 184.89 W | Type 3 | |
| WP9L2-108L-550-4K7-3-BC-CP | 4000 K | 70 CRI | 10260 lm | 55 | 184.89 W | Type 3 | |
| WP9L2-108L-550-4K7-3-BC | 4000 K | 70 CRI | 13152 lm | 71 | 184.89 W | Type 3 | |
| WP9L2-108L-550-4K7-3-CLR | 4000 K | 70 CRI | 18066 lm | 98 | 184.89 W | Type 3 | |
| WP9L2-108L-550-4K7-3-CP | 4000 K | 70 CRI | 16503 lm | 89 | 184.89 W | Type 3 | |
| WP9L2-108L-550-4K7-3 | 4000 K | 70 CRI | 21155 lm | 114 | 184.89 W | Type 3 | |
| WP9L2-108L-550-4K7-4-BC-CLR | 4000 K | 70 CRI | 13729 lm | 74 | 184.89 W | Type 4 | |
| WP9L2-108L-550-4K7-4-BC-CP | 4000 K | 70 CRI | 12541 lm | 68 | 184.89 W | Type 4 | |
| WP9L2-108L-550-4K7-4-BC | 4000 K | 70 CRI | 16076 lm | 87 | 184.89 W | Type 4 | |
| WP9L2-108L-550-4K7-4-CLR | 4000 K | 70 CRI | 18981 lm | 103 | 184.89 W | Type 4 | |
| WP9L2-108L-550-4K7-4-CP | 4000 K | 70 CRI | 17339 lm | 94 | 184.89 W | Type 4 | |
| WP9L2-108L-550-4K7-4 | 4000 K | 70 CRI | 22227 lm | 120 | 184.89 W | Type 4 | |
| WP9L2-108L-550-4K7-4W-BC-CLR | 4000 K | 70 CRI | 11609 lm | 63 | 184.89 W | Type 4W | |
| WP9L2-108L-550-4K7-4W-BC-CP | 4000 K | 70 CRI | 10604 lm | 57 | 184.89 W | Type 4W | |
| WP9L2-108L-550-4K7-4W-BC | 4000 K | 70 CRI | 13594 lm | 74 | 184.89 W | Type 4W | |
| WP9L2-108L-550-4K7-4W-CLR | 4000 K | 70 CRI | 18097 lm | 98 | 184.89 W | Type 4W | |
| WP9L2-108L-550-4K7-4W-CP | 4000 K | 70 CRI | 16531 lm | 89 | 184.89 W | Type 4W | |
| WP9L2-108L-550-4K7-4W | 4000 K | 70 CRI | 21192 lm | 115 | 184.89 W | Type 4W | |
| WP9L2-108L-550-4K7-5Q-CLR | 4000 K | 70 CRI | 18765 lm | 101 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-4K7-5Q-CP | 4000 K | 70 CRI | 17141 lm | 93 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-4K7-5Q | 4000 K | 70 CRI | 21973 lm | 119 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-4K7-L-CLR | 4000 K | 70 CRI | 18012 lm | 97 | 184.89 W | Type L | |
| WP9L2-108L-550-4K7-L-CP | 4000 K | 70 CRI | 16453 lm | 89 | 184.89 W | Type L | |
| WP9L2-108L-550-4K7-L | 4000 K | 70 CRI | 21092 lm | 114 | 184.89 W | Type L | |
| WP9L2-108L-550-4K7-R-CLR | 4000 K | 70 CRI | 18012 lm | 97 | 184.89 W | Type R | |
| WP9L2-108L-550-4K7-R-CP | 4000 K | 70 CRI | 16454 lm | 89 | 184.89 W | Type R | |
| WP9L2-108L-550-4K7-R | 4000 K | 70 CRI | 21092 lm | 114 | 184.89 W | Type R | |
| WP9L2-108L-550-5K7-1-BC-CLR | 5000 K | 70 CRI | 12939 lm | 70 | 184.89 W | Type 1 | |
| WP9L2-108L-550-5K7-1-BC-CP | 5000 K | 70 CRI | 11819 lm | 64 | 184.89 W | Type 1 | |
| WP9L2-108L-550-5K7-1-BC | 5000 K | 70 CRI | 15151 lm | 82 | 184.89 W | Type 1 | |
| WP9L2-108L-550-5K7-1-CLR | 5000 K | 70 CRI | 20210 lm | 109 | 184.89 W | Type 1 | |
| WP9L2-108L-550-5K7-1-CP | 5000 K | 70 CRI | 18462 lm | 100 | 184.89 W | Type 1 | |
| WP9L2-108L-550-5K7-1 | 5000 K | 70 CRI | 23666 lm | 128 | 184.89 W | Type 1 | |
| WP9L2-108L-550-5K7-2-BC-CLR | 5000 K | 70 CRI | 12082 lm | 65 | 184.89 W | Type 2 | |
| WP9L2-108L-550-5K7-2-BC-CP | 5000 K | 70 CRI | 11037 lm | 60 | 184.89 W | Type 2 | |
| WP9L2-108L-550-5K7-2-BC | 5000 K | 70 CRI | 14148 lm | 77 | 184.89 W | Type 2 | |
| WP9L2-108L-550-5K7-2-CLR | 5000 K | 70 CRI | 18968 lm | 103 | 184.89 W | Type 2 | |
| WP9L2-108L-550-5K7-2-CP | 5000 K | 70 CRI | 17327 lm | 94 | 184.89 W | Type 2 | |
| WP9L2-108L-550-5K7-2 | 5000 K | 70 CRI | 22211 lm | 120 | 184.89 W | Type 2 | |
| WP9L2-108L-550-5K7-3-BC-CLR | 5000 K | 70 CRI | 11695 lm | 63 | 184.89 W | Type 3 | |
| WP9L2-108L-550-5K7-3-BC-CP | 5000 K | 70 CRI | 10683 lm | 58 | 184.89 W | Type 3 | |
| WP9L2-108L-550-5K7-3-BC | 5000 K | 70 CRI | 13695 lm | 74 | 184.89 W | Type 3 | |
| WP9L2-108L-550-5K7-3-CLR | 5000 K | 70 CRI | 18811 lm | 102 | 184.89 W | Type 3 | |
| WP9L2-108L-550-5K7-3-CP | 5000 K | 70 CRI | 17184 lm | 93 | 184.89 W | Type 3 | |
| WP9L2-108L-550-5K7-3 | 5000 K | 70 CRI | 22028 lm | 119 | 184.89 W | Type 3 | |
| WP9L2-108L-550-5K7-4-BC-CLR | 5000 K | 70 CRI | 14295 lm | 77 | 184.89 W | Type 4 | |
| WP9L2-108L-550-5K7-4-BC-CP | 5000 K | 70 CRI | 13058 lm | 71 | 184.89 W | Type 4 | |
| WP9L2-108L-550-5K7-4-BC | 5000 K | 70 CRI | 16740 lm | 91 | 184.89 W | Type 4 | |
| WP9L2-108L-550-5K7-4-CLR | 5000 K | 70 CRI | 19764 lm | 107 | 184.89 W | Type 4 | |
| WP9L2-108L-550-5K7-4-CP | 5000 K | 70 CRI | 18054 lm | 98 | 184.89 W | Type 4 | |
| WP9L2-108L-550-5K7-4 | 5000 K | 70 CRI | 23144 lm | 125 | 184.89 W | Type 4 | |
| WP9L2-108L-550-5K7-4W-BC-CLR | 5000 K | 70 CRI | 12087 lm | 65 | 184.89 W | Type 4W | |
| WP9L2-108L-550-5K7-4W-BC-CP | 5000 K | 70 CRI | 11042 lm | 60 | 184.89 W | Type 4W | |
| WP9L2-108L-550-5K7-4W-BC | 5000 K | 70 CRI | 14154 lm | 77 | 184.89 W | Type 4W | |
| WP9L2-108L-550-5K7-4W-CLR | 5000 K | 70 CRI | 18843 lm | 102 | 184.89 W | Type 4W | |
| WP9L2-108L-550-5K7-4W-CP | 5000 K | 70 CRI | 17213 lm | 93 | 184.89 W | Type 4W | |
| WP9L2-108L-550-5K7-4W | 5000 K | 70 CRI | 22066 lm | 119 | 184.89 W | Type 4W | |
| WP9L2-108L-550-5K7-5Q-CLR | 5000 K | 70 CRI | 19539 lm | 106 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-5K7-5Q-CP | 5000 K | 70 CRI | 17848 lm | 97 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-5K7-5Q | 5000 K | 70 CRI | 22880 lm | 124 | 184.89 W | Type 5Q | |
| WP9L2-108L-550-5K7-L-CLR | 5000 K | 70 CRI | 18755 lm | 101 | 184.89 W | Type L | |
| WP9L2-108L-550-5K7-L-CP | 5000 K | 70 CRI | 17133 lm | 93 | 184.89 W | Type L | |
| WP9L2-108L-550-5K7-L | 5000 K | 70 CRI | 21963 lm | 119 | 184.89 W | Type L | |
| WP9L2-108L-550-5K7-R-CLR | 5000 K | 70 CRI | 18756 lm | 101 | 184.89 W | Type R | |
| WP9L2-108L-550-5K7-R-CP | 5000 K | 70 CRI | 17133 lm | 93 | 184.89 W | Type R | |
| WP9L2-108L-550-5K7-R | 5000 K | 70 CRI | 21963 lm | 119 | 184.89 W | Type R | |
| WP9L2-108L-700-3K7-1-BC-CLR | 3000 K | 70 CRI | 14421 lm | 61 | 235.6 W | Type 1 | |
| WP9L2-108L-700-3K7-1-BC-CP | 3000 K | 70 CRI | 13173 lm | 56 | 235.6 W | Type 1 | |
| WP9L2-108L-700-3K7-1-BC | 3000 K | 70 CRI | 16887 lm | 72 | 235.6 W | Type 1 | |
| WP9L2-108L-700-3K7-1-CLR | 3000 K | 70 CRI | 22525 lm | 96 | 235.6 W | Type 1 | |
| WP9L2-108L-700-3K7-1-CP | 3000 K | 70 CRI | 20576 lm | 87 | 235.6 W | Type 1 | |
| WP9L2-108L-700-3K7-1 | 3000 K | 70 CRI | 26376 lm | 112 | 235.6 W | Type 1 | |
| WP9L2-108L-700-3K7-2-BC-CLR | 3000 K | 70 CRI | 13466 lm | 57 | 235.6 W | Type 2 | |
| WP9L2-108L-700-3K7-2-BC-CP | 3000 K | 70 CRI | 12301 lm | 52 | 235.6 W | Type 2 | |
| WP9L2-108L-700-3K7-2-BC | 3000 K | 70 CRI | 15768 lm | 67 | 235.6 W | Type 2 | |
| WP9L2-108L-700-3K7-2-CLR | 3000 K | 70 CRI | 21140 lm | 90 | 235.6 W | Type 2 | |
| WP9L2-108L-700-3K7-2-CP | 3000 K | 70 CRI | 19311 lm | 82 | 235.6 W | Type 2 | |
| WP9L2-108L-700-3K7-2 | 3000 K | 70 CRI | 24755 lm | 105 | 235.6 W | Type 2 | |
| WP9L2-108L-700-3K7-3-BC-CLR | 3000 K | 70 CRI | 13034 lm | 55 | 235.6 W | Type 3 | |
| WP9L2-108L-700-3K7-3-BC-CP | 3000 K | 70 CRI | 11907 lm | 51 | 235.6 W | Type 3 | |
| WP9L2-108L-700-3K7-3-BC | 3000 K | 70 CRI | 15263 lm | 65 | 235.6 W | Type 3 | |
| WP9L2-108L-700-3K7-3-CLR | 3000 K | 70 CRI | 20966 lm | 89 | 235.6 W | Type 3 | |
| WP9L2-108L-700-3K7-3-CP | 3000 K | 70 CRI | 19152 lm | 81 | 235.6 W | Type 3 | |
| WP9L2-108L-700-3K7-3 | 3000 K | 70 CRI | 24551 lm | 104 | 235.6 W | Type 3 | |
| WP9L2-108L-700-3K7-4-BC-CLR | 3000 K | 70 CRI | 15932 lm | 68 | 235.59 W | Type 4 | |
| WP9L2-108L-700-3K7-4-BC-CP | 3000 K | 70 CRI | 14554 lm | 62 | 235.59 W | Type 4 | |
| WP9L2-108L-700-3K7-4-BC | 3000 K | 70 CRI | 18657 lm | 79 | 235.59 W | Type 4 | |
| WP9L2-108L-700-3K7-4-CLR | 3000 K | 70 CRI | 22028 lm | 94 | 235.59 W | Type 4 | |
| WP9L2-108L-700-3K7-4-CP | 3000 K | 70 CRI | 20122 lm | 85 | 235.59 W | Type 4 | |
| WP9L2-108L-700-3K7-4 | 3000 K | 70 CRI | 25795 lm | 109 | 235.59 W | Type 4 | |
| WP9L2-108L-700-3K7-4W-BC-CLR | 3000 K | 70 CRI | 13472 lm | 57 | 235.6 W | Type 4W | |
| WP9L2-108L-700-3K7-4W-BC-CP | 3000 K | 70 CRI | 12306 lm | 52 | 235.6 W | Type 4W | |
| WP9L2-108L-700-3K7-4W-BC | 3000 K | 70 CRI | 15776 lm | 67 | 235.6 W | Type 4W | |
| WP9L2-108L-700-3K7-4W-CLR | 3000 K | 70 CRI | 21002 lm | 89 | 235.6 W | Type 4W | |
| WP9L2-108L-700-3K7-4W-CP | 3000 K | 70 CRI | 19185 lm | 81 | 235.6 W | Type 4W | |
| WP9L2-108L-700-3K7-4W | 3000 K | 70 CRI | 24593 lm | 104 | 235.6 W | Type 4W | |
| WP9L2-108L-700-3K7-5Q-CLR | 3000 K | 70 CRI | 21776 lm | 92 | 235.6 W | Type 5Q | |
| WP9L2-108L-700-3K7-5Q-CP | 3000 K | 70 CRI | 19892 lm | 84 | 235.6 W | Type 5Q | |
| WP9L2-108L-700-3K7-5Q | 3000 K | 70 CRI | 25500 lm | 108 | 235.6 W | Type 5Q | |
| WP9L2-108L-700-3K7-L-CLR | 3000 K | 70 CRI | 20903 lm | 89 | 235.6 W | Type L | |
| WP9L2-108L-700-3K7-L-CP | 3000 K | 70 CRI | 19095 lm | 81 | 235.6 W | Type L | |
| WP9L2-108L-700-3K7-L | 3000 K | 70 CRI | 24478 lm | 104 | 235.6 W | Type L | |
| WP9L2-108L-700-3K7-R-CLR | 3000 K | 70 CRI | 20903 lm | 89 | 235.6 W | Type R | |
| WP9L2-108L-700-3K7-R-CP | 3000 K | 70 CRI | 19095 lm | 81 | 235.6 W | Type R | |
| WP9L2-108L-700-3K7-R | 3000 K | 70 CRI | 24478 lm | 104 | 235.6 W | Type R | |
| WP9L2-108L-700-4K7-1-BC-CLR | 4000 K | 70 CRI | 14965 lm | 64 | 235.6 W | Type 1 | |
| WP9L2-108L-700-4K7-1-BC-CP | 4000 K | 70 CRI | 13670 lm | 58 | 235.6 W | Type 1 | |
| WP9L2-108L-700-4K7-1-BC | 4000 K | 70 CRI | 17524 lm | 74 | 235.6 W | Type 1 | |
| WP9L2-108L-700-4K7-1-CLR | 4000 K | 70 CRI | 23375 lm | 99 | 235.6 W | Type 1 | |
| WP9L2-108L-700-4K7-1-CP | 4000 K | 70 CRI | 21353 lm | 91 | 235.6 W | Type 1 | |
| WP9L2-108L-700-4K7-1 | 4000 K | 70 CRI | 27372 lm | 116 | 235.6 W | Type 1 | |
| WP9L2-108L-700-4K7-2-BC-CLR | 4000 K | 70 CRI | 13974 lm | 59 | 235.6 W | Type 2 | |
| WP9L2-108L-700-4K7-2-BC-CP | 4000 K | 70 CRI | 12765 lm | 54 | 235.6 W | Type 2 | |
| WP9L2-108L-700-4K7-2-BC | 4000 K | 70 CRI | 16364 lm | 69 | 235.6 W | Type 2 | |
| WP9L2-108L-700-4K7-2-CLR | 4000 K | 70 CRI | 21938 lm | 93 | 235.6 W | Type 2 | |
| WP9L2-108L-700-4K7-2-CP | 4000 K | 70 CRI | 20040 lm | 85 | 235.6 W | Type 2 | |
| WP9L2-108L-700-4K7-2 | 4000 K | 70 CRI | 25690 lm | 109 | 235.6 W | Type 2 | |
| WP9L2-108L-700-4K7-3-BC-CLR | 4000 K | 70 CRI | 13526 lm | 57 | 235.6 W | Type 3 | |
| WP9L2-108L-700-4K7-3-BC-CP | 4000 K | 70 CRI | 12356 lm | 52 | 235.6 W | Type 3 | |
| WP9L2-108L-700-4K7-3-BC | 4000 K | 70 CRI | 15840 lm | 67 | 235.6 W | Type 3 | |
| WP9L2-108L-700-4K7-3-CLR | 4000 K | 70 CRI | 21757 lm | 92 | 235.6 W | Type 3 | |
| WP9L2-108L-700-4K7-3-CP | 4000 K | 70 CRI | 19875 lm | 84 | 235.6 W | Type 3 | |
| WP9L2-108L-700-4K7-3 | 4000 K | 70 CRI | 25478 lm | 108 | 235.6 W | Type 3 | |
| WP9L2-108L-700-4K7-4-BC-CLR | 4000 K | 70 CRI | 16534 lm | 70 | 235.59 W | Type 4 | |
| WP9L2-108L-700-4K7-4-BC-CP | 4000 K | 70 CRI | 15104 lm | 64 | 235.59 W | Type 4 | |
| WP9L2-108L-700-4K7-4-BC | 4000 K | 70 CRI | 19361 lm | 82 | 235.59 W | Type 4 | |
| WP9L2-108L-700-4K7-4-CLR | 4000 K | 70 CRI | 22859 lm | 97 | 235.59 W | Type 4 | |
| WP9L2-108L-700-4K7-4-CP | 4000 K | 70 CRI | 20882 lm | 89 | 235.59 W | Type 4 | |
| WP9L2-108L-700-4K7-4 | 4000 K | 70 CRI | 26768 lm | 114 | 235.59 W | Type 4 | |
| WP9L2-108L-700-4K7-4W-BC-CLR | 4000 K | 70 CRI | 13981 lm | 59 | 235.6 W | Type 4W | |
| WP9L2-108L-700-4K7-4W-BC-CP | 4000 K | 70 CRI | 12771 lm | 54 | 235.6 W | Type 4W | |
| WP9L2-108L-700-4K7-4W-BC | 4000 K | 70 CRI | 16371 lm | 69 | 235.6 W | Type 4W | |
| WP9L2-108L-700-4K7-4W-CLR | 4000 K | 70 CRI | 21795 lm | 93 | 235.6 W | Type 4W | |
| WP9L2-108L-700-4K7-4W-CP | 4000 K | 70 CRI | 19909 lm | 85 | 235.6 W | Type 4W | |
| WP9L2-108L-700-4K7-4W | 4000 K | 70 CRI | 25522 lm | 108 | 235.6 W | Type 4W | |
| WP9L2-108L-700-4K7-5Q-CLR | 4000 K | 70 CRI | 22599 lm | 96 | 235.6 W | Type 5Q | |
| WP9L2-108L-700-4K7-5Q-CP | 4000 K | 70 CRI | 20644 lm | 88 | 235.6 W | Type 5Q | |
| WP9L2-108L-700-4K7-5Q | 4000 K | 70 CRI | 26463 lm | 112 | 235.6 W | Type 5Q | |
| WP9L2-108L-700-4K7-L-CLR | 4000 K | 70 CRI | 21693 lm | 92 | 235.6 W | Type L | |
| WP9L2-108L-700-4K7-L-CP | 4000 K | 70 CRI | 19816 lm | 84 | 235.6 W | Type L | |
| WP9L2-108L-700-4K7-L | 4000 K | 70 CRI | 25402 lm | 108 | 235.6 W | Type L | |
| WP9L2-108L-700-4K7-R-CLR | 4000 K | 70 CRI | 21693 lm | 92 | 235.6 W | Type R | |
| WP9L2-108L-700-4K7-R-CP | 4000 K | 70 CRI | 19816 lm | 84 | 235.6 W | Type R | |
| WP9L2-108L-700-4K7-R | 4000 K | 70 CRI | 25402 lm | 108 | 235.6 W | Type R | |
| WP9L2-108L-700-5K7-1-BC-CLR | 5000 K | 70 CRI | 15582 lm | 66 | 234.99 W | Type 1 | |
| WP9L2-108L-700-5K7-1-BC-CP | 5000 K | 70 CRI | 14234 lm | 61 | 234.99 W | Type 1 | |
| WP9L2-108L-700-5K7-1-BC | 5000 K | 70 CRI | 18247 lm | 78 | 234.99 W | Type 1 | |
| WP9L2-108L-700-5K7-1-CLR | 5000 K | 70 CRI | 24339 lm | 103 | 235.26 W | Type 1 | |
| WP9L2-108L-700-5K7-1-CP | 5000 K | 70 CRI | 22234 lm | 95 | 235.26 W | Type 1 | |
| WP9L2-108L-700-5K7-1 | 5000 K | 70 CRI | 28501 lm | 121 | 235.26 W | Type 1 | |
| WP9L2-108L-700-5K7-2-BC-CLR | 5000 K | 70 CRI | 14550 lm | 62 | 234.53 W | Type 2 | |
| WP9L2-108L-700-5K7-2-BC-CP | 5000 K | 70 CRI | 13292 lm | 57 | 234.53 W | Type 2 | |
| WP9L2-108L-700-5K7-2-BC | 5000 K | 70 CRI | 17039 lm | 73 | 234.53 W | Type 2 | |
| WP9L2-108L-700-5K7-2-CLR | 5000 K | 70 CRI | 22843 lm | 97 | 234.83 W | Type 2 | |
| WP9L2-108L-700-5K7-2-CP | 5000 K | 70 CRI | 20867 lm | 89 | 234.83 W | Type 2 | |
| WP9L2-108L-700-5K7-2 | 5000 K | 70 CRI | 26749 lm | 114 | 234.83 W | Type 2 | |
| WP9L2-108L-700-5K7-3-BC-CLR | 5000 K | 70 CRI | 14084 lm | 60 | 234.07 W | Type 3 | |
| WP9L2-108L-700-5K7-3-BC-CP | 5000 K | 70 CRI | 12866 lm | 55 | 234.07 W | Type 3 | |
| WP9L2-108L-700-5K7-3-BC | 5000 K | 70 CRI | 16493 lm | 70 | 234.07 W | Type 3 | |
| WP9L2-108L-700-5K7-3-CLR | 5000 K | 70 CRI | 22655 lm | 96 | 236.19 W | Type 3 | |
| WP9L2-108L-700-5K7-3-CP | 5000 K | 70 CRI | 20695 lm | 88 | 236.19 W | Type 3 | |
| WP9L2-108L-700-5K7-3 | 5000 K | 70 CRI | 26529 lm | 112 | 236.19 W | Type 3 | |
| WP9L2-108L-700-5K7-4-BC-CLR | 5000 K | 70 CRI | 17216 lm | 73 | 235.59 W | Type 4 | |
| WP9L2-108L-700-5K7-4-BC-CP | 5000 K | 70 CRI | 15727 lm | 67 | 235.59 W | Type 4 | |
| WP9L2-108L-700-5K7-4-BC | 5000 K | 70 CRI | 20160 lm | 86 | 234.77 W | Type 4 | |
| WP9L2-108L-700-5K7-4-CLR | 5000 K | 70 CRI | 23802 lm | 101 | 235.59 W | Type 4 | |
| WP9L2-108L-700-5K7-4-CP | 5000 K | 70 CRI | 21743 lm | 92 | 235.59 W | Type 4 | |
| WP9L2-108L-700-5K7-4 | 5000 K | 70 CRI | 27873 lm | 118 | 235.55 W | Type 4 | |
| WP9L2-108L-700-5K7-4W-BC-CLR | 5000 K | 70 CRI | 14557 lm | 62 | 234.82 W | Type 4W | |
| WP9L2-108L-700-5K7-4W-BC-CP | 5000 K | 70 CRI | 13298 lm | 57 | 234.82 W | Type 4W | |
| WP9L2-108L-700-5K7-4W-BC | 5000 K | 70 CRI | 17047 lm | 73 | 234.82 W | Type 4W | |
| WP9L2-108L-700-5K7-4W-CLR | 5000 K | 70 CRI | 22694 lm | 96 | 235.38 W | Type 4W | |
| WP9L2-108L-700-5K7-4W-CP | 5000 K | 70 CRI | 20730 lm | 88 | 235.38 W | Type 4W | |
| WP9L2-108L-700-5K7-4W | 5000 K | 70 CRI | 26574 lm | 113 | 235.38 W | Type 4W | |
| WP9L2-108L-700-5K7-5Q-CLR | 5000 K | 70 CRI | 23531 lm | 99 | 236.51 W | Type 5Q | |
| WP9L2-108L-700-5K7-5Q-CP | 5000 K | 70 CRI | 21495 lm | 91 | 236.51 W | Type 5Q | |
| WP9L2-108L-700-5K7-5Q | 5000 K | 70 CRI | 27555 lm | 117 | 236.51 W | Type 5Q | |
| WP9L2-108L-700-5K7-L-CLR | 5000 K | 70 CRI | 22587 lm | 95 | 236.52 W | Type L | |
| WP9L2-108L-700-5K7-L-CP | 5000 K | 70 CRI | 20633 lm | 87 | 236.52 W | Type L | |
| WP9L2-108L-700-5K7-L | 5000 K | 70 CRI | 26450 lm | 112 | 236.52 W | Type L | |
| WP9L2-108L-700-5K7-R-CLR | 5000 K | 70 CRI | 22587 lm | 95 | 236.52 W | Type R | |
| WP9L2-108L-700-5K7-R-CP | 5000 K | 70 CRI | 20633 lm | 87 | 236.52 W | Type R | |
| WP9L2-108L-700-5K7-R | 5000 K | 70 CRI | 26450 lm | 112 | 236.52 W | Type R | |
| WP9L2-81L-550-3K7-1-BC-CLR | 3000 K | 70 CRI | 9027 lm | 65 | 138.03 W | Type 1 | |
| WP9L2-81L-550-3K7-1-BC-CP | 3000 K | 70 CRI | 8246 lm | 60 | 138.03 W | Type 1 | |
| WP9L2-81L-550-3K7-1-BC | 3000 K | 70 CRI | 10571 lm | 77 | 138.03 W | Type 1 | |
| WP9L2-81L-550-3K7-1-CLR | 3000 K | 70 CRI | 14100 lm | 102 | 138.03 W | Type 1 | |
| WP9L2-81L-550-3K7-1-CP | 3000 K | 70 CRI | 12880 lm | 93 | 138.03 W | Type 1 | |
| WP9L2-81L-550-3K7-1 | 3000 K | 70 CRI | 16511 lm | 120 | 138.03 W | Type 1 | |
| WP9L2-81L-550-3K7-2-BC-CLR | 3000 K | 70 CRI | 8429 lm | 61 | 138.03 W | Type 2 | |
| WP9L2-81L-550-3K7-2-BC-CP | 3000 K | 70 CRI | 7700 lm | 56 | 138.03 W | Type 2 | |
| WP9L2-81L-550-3K7-2-BC | 3000 K | 70 CRI | 9871 lm | 72 | 138.03 W | Type 2 | |
| WP9L2-81L-550-3K7-2-CLR | 3000 K | 70 CRI | 13233 lm | 96 | 138.03 W | Type 2 | |
| WP9L2-81L-550-3K7-2-CP | 3000 K | 70 CRI | 12089 lm | 88 | 138.03 W | Type 2 | |
| WP9L2-81L-550-3K7-2 | 3000 K | 70 CRI | 15496 lm | 112 | 138.03 W | Type 2 | |
| WP9L2-81L-550-3K7-3-BC-CLR | 3000 K | 70 CRI | 8159 lm | 59 | 138.03 W | Type 3 | |
| WP9L2-81L-550-3K7-3-BC-CP | 3000 K | 70 CRI | 7454 lm | 54 | 138.03 W | Type 3 | |
| WP9L2-81L-550-3K7-3-BC | 3000 K | 70 CRI | 9555 lm | 69 | 138.03 W | Type 3 | |
| WP9L2-81L-550-3K7-3-CLR | 3000 K | 70 CRI | 13124 lm | 95 | 138.03 W | Type 3 | |
| WP9L2-81L-550-3K7-3-CP | 3000 K | 70 CRI | 11989 lm | 87 | 138.03 W | Type 3 | |
| WP9L2-81L-550-3K7-3 | 3000 K | 70 CRI | 15369 lm | 111 | 138.03 W | Type 3 | |
| WP9L2-81L-550-3K7-4-BC-CLR | 3000 K | 70 CRI | 9974 lm | 72 | 138.03 W | Type 4 | |
| WP9L2-81L-550-3K7-4-BC-CP | 3000 K | 70 CRI | 9111 lm | 66 | 138.03 W | Type 4 | |
| WP9L2-81L-550-3K7-4-BC | 3000 K | 70 CRI | 11679 lm | 85 | 138.03 W | Type 4 | |
| WP9L2-81L-550-3K7-4-CLR | 3000 K | 70 CRI | 13789 lm | 100 | 138.03 W | Type 4 | |
| WP9L2-81L-550-3K7-4-CP | 3000 K | 70 CRI | 12596 lm | 91 | 138.03 W | Type 4 | |
| WP9L2-81L-550-3K7-4 | 3000 K | 70 CRI | 16147 lm | 117 | 138.03 W | Type 4 | |
| WP9L2-81L-550-3K7-4W-BC-CLR | 3000 K | 70 CRI | 8433 lm | 61 | 138.03 W | Type 4W | |
| WP9L2-81L-550-3K7-4W-BC-CP | 3000 K | 70 CRI | 7704 lm | 56 | 138.03 W | Type 4W | |
| WP9L2-81L-550-3K7-4W-BC | 3000 K | 70 CRI | 9875 lm | 72 | 138.03 W | Type 4W | |
| WP9L2-81L-550-3K7-4W-CLR | 3000 K | 70 CRI | 13147 lm | 95 | 138.03 W | Type 4W | |
| WP9L2-81L-550-3K7-4W-CP | 3000 K | 70 CRI | 12009 lm | 87 | 138.03 W | Type 4W | |
| WP9L2-81L-550-3K7-4W | 3000 K | 70 CRI | 15395 lm | 112 | 138.03 W | Type 4W | |
| WP9L2-81L-550-3K7-5Q-CLR | 3000 K | 70 CRI | 13632 lm | 99 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-3K7-5Q-CP | 3000 K | 70 CRI | 12453 lm | 90 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-3K7-5Q | 3000 K | 70 CRI | 15963 lm | 116 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-3K7-L-CLR | 3000 K | 70 CRI | 13086 lm | 95 | 138.03 W | Type L | |
| WP9L2-81L-550-3K7-L-CP | 3000 K | 70 CRI | 11954 lm | 87 | 138.03 W | Type L | |
| WP9L2-81L-550-3K7-L | 3000 K | 70 CRI | 15324 lm | 111 | 138.03 W | Type L | |
| WP9L2-81L-550-3K7-R-CLR | 3000 K | 70 CRI | 13086 lm | 95 | 138.03 W | Type R | |
| WP9L2-81L-550-3K7-R-CP | 3000 K | 70 CRI | 11954 lm | 87 | 138.03 W | Type R | |
| WP9L2-81L-550-3K7-R | 3000 K | 70 CRI | 15323 lm | 111 | 138.03 W | Type R | |
| WP9L2-81L-550-4K7-1-BC-CLR | 4000 K | 70 CRI | 9368 lm | 68 | 138.03 W | Type 1 | |
| WP9L2-81L-550-4K7-1-BC-CP | 4000 K | 70 CRI | 8558 lm | 62 | 138.03 W | Type 1 | |
| WP9L2-81L-550-4K7-1-BC | 4000 K | 70 CRI | 10970 lm | 79 | 138.03 W | Type 1 | |
| WP9L2-81L-550-4K7-1-CLR | 4000 K | 70 CRI | 14633 lm | 106 | 138.03 W | Type 1 | |
| WP9L2-81L-550-4K7-1-CP | 4000 K | 70 CRI | 13367 lm | 97 | 138.03 W | Type 1 | |
| WP9L2-81L-550-4K7-1 | 4000 K | 70 CRI | 17135 lm | 124 | 138.03 W | Type 1 | |
| WP9L2-81L-550-4K7-2-BC-CLR | 4000 K | 70 CRI | 8748 lm | 63 | 138.03 W | Type 2 | |
| WP9L2-81L-550-4K7-2-BC-CP | 4000 K | 70 CRI | 7991 lm | 58 | 138.03 W | Type 2 | |
| WP9L2-81L-550-4K7-2-BC | 4000 K | 70 CRI | 10243 lm | 74 | 138.03 W | Type 2 | |
| WP9L2-81L-550-4K7-2-CLR | 4000 K | 70 CRI | 13733 lm | 99 | 138.03 W | Type 2 | |
| WP9L2-81L-550-4K7-2-CP | 4000 K | 70 CRI | 12545 lm | 91 | 138.03 W | Type 2 | |
| WP9L2-81L-550-4K7-2 | 4000 K | 70 CRI | 16081 lm | 117 | 138.03 W | Type 2 | |
| WP9L2-81L-550-4K7-3-BC-CLR | 4000 K | 70 CRI | 8468 lm | 61 | 138.03 W | Type 3 | |
| WP9L2-81L-550-4K7-3-BC-CP | 4000 K | 70 CRI | 7735 lm | 56 | 138.03 W | Type 3 | |
| WP9L2-81L-550-4K7-3-BC | 4000 K | 70 CRI | 9915 lm | 72 | 138.03 W | Type 3 | |
| WP9L2-81L-550-4K7-3-CLR | 4000 K | 70 CRI | 13620 lm | 99 | 138.03 W | Type 3 | |
| WP9L2-81L-550-4K7-3-CP | 4000 K | 70 CRI | 12442 lm | 90 | 138.03 W | Type 3 | |
| WP9L2-81L-550-4K7-3 | 4000 K | 70 CRI | 15949 lm | 116 | 138.03 W | Type 3 | |
| WP9L2-81L-550-4K7-4-BC-CLR | 4000 K | 70 CRI | 10350 lm | 75 | 138.03 W | Type 4 | |
| WP9L2-81L-550-4K7-4-BC-CP | 4000 K | 70 CRI | 9455 lm | 68 | 138.03 W | Type 4 | |
| WP9L2-81L-550-4K7-4-BC | 4000 K | 70 CRI | 12120 lm | 88 | 138.03 W | Type 4 | |
| WP9L2-81L-550-4K7-4-CLR | 4000 K | 70 CRI | 14310 lm | 104 | 138.03 W | Type 4 | |
| WP9L2-81L-550-4K7-4-CP | 4000 K | 70 CRI | 13072 lm | 95 | 138.03 W | Type 4 | |
| WP9L2-81L-550-4K7-4 | 4000 K | 70 CRI | 16757 lm | 121 | 138.03 W | Type 4 | |
| WP9L2-81L-550-4K7-4W-BC-CLR | 4000 K | 70 CRI | 8752 lm | 63 | 138.03 W | Type 4W | |
| WP9L2-81L-550-4K7-4W-BC-CP | 4000 K | 70 CRI | 7995 lm | 58 | 138.03 W | Type 4W | |
| WP9L2-81L-550-4K7-4W-BC | 4000 K | 70 CRI | 10248 lm | 74 | 138.03 W | Type 4W | |
| WP9L2-81L-550-4K7-4W-CLR | 4000 K | 70 CRI | 13643 lm | 99 | 138.03 W | Type 4W | |
| WP9L2-81L-550-4K7-4W-CP | 4000 K | 70 CRI | 12463 lm | 90 | 138.03 W | Type 4W | |
| WP9L2-81L-550-4K7-4W | 4000 K | 70 CRI | 15976 lm | 116 | 138.03 W | Type 4W | |
| WP9L2-81L-550-4K7-5Q-CLR | 4000 K | 70 CRI | 14147 lm | 102 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-4K7-5Q-CP | 4000 K | 70 CRI | 12923 lm | 94 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-4K7-5Q | 4000 K | 70 CRI | 16566 lm | 120 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-4K7-L-CLR | 4000 K | 70 CRI | 13579 lm | 98 | 138.03 W | Type L | |
| WP9L2-81L-550-4K7-L-CP | 4000 K | 70 CRI | 12405 lm | 90 | 138.03 W | Type L | |
| WP9L2-81L-550-4K7-L | 4000 K | 70 CRI | 15902 lm | 115 | 138.03 W | Type L | |
| WP9L2-81L-550-4K7-R-CLR | 4000 K | 70 CRI | 13580 lm | 98 | 138.03 W | Type R | |
| WP9L2-81L-550-4K7-R-CP | 4000 K | 70 CRI | 12405 lm | 90 | 138.03 W | Type R | |
| WP9L2-81L-550-4K7-R | 4000 K | 70 CRI | 15902 lm | 115 | 138.03 W | Type R | |
| WP9L2-81L-550-5K7-1-BC-CLR | 5000 K | 70 CRI | 9755 lm | 71 | 138.03 W | Type 1 | |
| WP9L2-81L-550-5K7-1-BC-CP | 5000 K | 70 CRI | 8911 lm | 65 | 138.03 W | Type 1 | |
| WP9L2-81L-550-5K7-1-BC | 5000 K | 70 CRI | 11423 lm | 83 | 138.03 W | Type 1 | |
| WP9L2-81L-550-5K7-1-CLR | 5000 K | 70 CRI | 15236 lm | 110 | 138.03 W | Type 1 | |
| WP9L2-81L-550-5K7-1-CP | 5000 K | 70 CRI | 13918 lm | 101 | 138.03 W | Type 1 | |
| WP9L2-81L-550-5K7-1 | 5000 K | 70 CRI | 17842 lm | 129 | 138.03 W | Type 1 | |
| WP9L2-81L-550-5K7-2-BC-CLR | 5000 K | 70 CRI | 9108 lm | 66 | 138.03 W | Type 2 | |
| WP9L2-81L-550-5K7-2-BC-CP | 5000 K | 70 CRI | 8320 lm | 60 | 138.03 W | Type 2 | |
| WP9L2-81L-550-5K7-2-BC | 5000 K | 70 CRI | 10666 lm | 77 | 138.03 W | Type 2 | |
| WP9L2-81L-550-5K7-2-CLR | 5000 K | 70 CRI | 14300 lm | 104 | 138.03 W | Type 2 | |
| WP9L2-81L-550-5K7-2-CP | 5000 K | 70 CRI | 13063 lm | 95 | 138.03 W | Type 2 | |
| WP9L2-81L-550-5K7-2 | 5000 K | 70 CRI | 16745 lm | 121 | 138.03 W | Type 2 | |
| WP9L2-81L-550-5K7-3-BC-CLR | 5000 K | 70 CRI | 8817 lm | 64 | 138.03 W | Type 3 | |
| WP9L2-81L-550-5K7-3-BC-CP | 5000 K | 70 CRI | 8054 lm | 58 | 138.03 W | Type 3 | |
| WP9L2-81L-550-5K7-3-BC | 5000 K | 70 CRI | 10324 lm | 75 | 138.03 W | Type 3 | |
| WP9L2-81L-550-5K7-3-CLR | 5000 K | 70 CRI | 14182 lm | 103 | 138.03 W | Type 3 | |
| WP9L2-81L-550-5K7-3-CP | 5000 K | 70 CRI | 12955 lm | 94 | 138.03 W | Type 3 | |
| WP9L2-81L-550-5K7-3 | 5000 K | 70 CRI | 16607 lm | 120 | 138.03 W | Type 3 | |
| WP9L2-81L-550-5K7-4-BC-CLR | 5000 K | 70 CRI | 10777 lm | 78 | 138.03 W | Type 4 | |
| WP9L2-81L-550-5K7-4-BC-CP | 5000 K | 70 CRI | 9845 lm | 71 | 138.03 W | Type 4 | |
| WP9L2-81L-550-5K7-4-BC | 5000 K | 70 CRI | 12620 lm | 91 | 138.03 W | Type 4 | |
| WP9L2-81L-550-5K7-4-CLR | 5000 K | 70 CRI | 14900 lm | 108 | 138.03 W | Type 4 | |
| WP9L2-81L-550-5K7-4-CP | 5000 K | 70 CRI | 13611 lm | 99 | 138.03 W | Type 4 | |
| WP9L2-81L-550-5K7-4 | 5000 K | 70 CRI | 17448 lm | 126 | 138.03 W | Type 4 | |
| WP9L2-81L-550-5K7-4W-BC-CLR | 5000 K | 70 CRI | 9113 lm | 66 | 138.03 W | Type 4W | |
| WP9L2-81L-550-5K7-4W-BC-CP | 5000 K | 70 CRI | 8324 lm | 60 | 138.03 W | Type 4W | |
| WP9L2-81L-550-5K7-4W-BC | 5000 K | 70 CRI | 10671 lm | 77 | 138.03 W | Type 4W | |
| WP9L2-81L-550-5K7-4W-CLR | 5000 K | 70 CRI | 14206 lm | 103 | 138.03 W | Type 4W | |
| WP9L2-81L-550-5K7-4W-CP | 5000 K | 70 CRI | 12977 lm | 94 | 138.03 W | Type 4W | |
| WP9L2-81L-550-5K7-4W | 5000 K | 70 CRI | 16635 lm | 121 | 138.03 W | Type 4W | |
| WP9L2-81L-550-5K7-5Q-CLR | 5000 K | 70 CRI | 14730 lm | 107 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-5K7-5Q-CP | 5000 K | 70 CRI | 13456 lm | 97 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-5K7-5Q | 5000 K | 70 CRI | 17249 lm | 125 | 138.03 W | Type 5Q | |
| WP9L2-81L-550-5K7-L-CLR | 5000 K | 70 CRI | 14140 lm | 102 | 138.03 W | Type L | |
| WP9L2-81L-550-5K7-L-CP | 5000 K | 70 CRI | 12917 lm | 94 | 138.03 W | Type L | |
| WP9L2-81L-550-5K7-L | 5000 K | 70 CRI | 16558 lm | 120 | 138.03 W | Type L | |
| WP9L2-81L-550-5K7-R-CLR | 5000 K | 70 CRI | 14140 lm | 102 | 138.03 W | Type R | |
| WP9L2-81L-550-5K7-R-CP | 5000 K | 70 CRI | 12917 lm | 94 | 138.03 W | Type R | |
| WP9L2-81L-550-5K7-R | 5000 K | 70 CRI | 16558 lm | 120 | 138.03 W | Type R | |
| WP9S2-27L-350-3K7-1-BC-CLR | 3000 K | 70 CRI | 2188 lm | 69 | 31.6 W | Type 1 | |
| WP9S2-27L-350-3K7-1-BC-CP | 3000 K | 70 CRI | 1989 lm | 63 | 31.6 W | Type 1 | |
| WP9S2-27L-350-3K7-1-BC | 3000 K | 70 CRI | 2483 lm | 79 | 31.6 W | Type 1 | |
| WP9S2-27L-350-3K7-1-CLR | 3000 K | 70 CRI | 3354 lm | 106 | 31.6 W | Type 1 | |
| WP9S2-27L-350-3K7-1-CP | 3000 K | 70 CRI | 3048 lm | 96 | 31.6 W | Type 1 | |
| WP9S2-27L-350-3K7-1 | 3000 K | 70 CRI | 3806 lm | 120 | 31.6 W | Type 1 | |
| WP9S2-27L-350-3K7-2-BC-CLR | 3000 K | 70 CRI | 2047 lm | 65 | 31.6 W | Type 2 | |
| WP9S2-27L-350-3K7-2-BC-CP | 3000 K | 70 CRI | 1860 lm | 59 | 31.6 W | Type 2 | |
| WP9S2-27L-350-3K7-2-BC | 3000 K | 70 CRI | 2322 lm | 73 | 31.6 W | Type 2 | |
| WP9S2-27L-350-3K7-2-CLR | 3000 K | 70 CRI | 3185 lm | 101 | 31.6 W | Type 2 | |
| WP9S2-27L-350-3K7-2-CP | 3000 K | 70 CRI | 2894 lm | 92 | 31.6 W | Type 2 | |
| WP9S2-27L-350-3K7-2 | 3000 K | 70 CRI | 3614 lm | 114 | 31.6 W | Type 2 | |
| WP9S2-27L-350-3K7-3-BC-CLR | 3000 K | 70 CRI | 1962 lm | 62 | 31.6 W | Type 3 | |
| WP9S2-27L-350-3K7-3-BC-CP | 3000 K | 70 CRI | 1783 lm | 56 | 31.6 W | Type 3 | |
| WP9S2-27L-350-3K7-3-BC | 3000 K | 70 CRI | 2227 lm | 70 | 31.6 W | Type 3 | |
| WP9S2-27L-350-3K7-3-CLR | 3000 K | 70 CRI | 3176 lm | 101 | 31.6 W | Type 3 | |
| WP9S2-27L-350-3K7-3-CP | 3000 K | 70 CRI | 2887 lm | 91 | 31.6 W | Type 3 | |
| WP9S2-27L-350-3K7-3 | 3000 K | 70 CRI | 3604 lm | 114 | 31.6 W | Type 3 | |
| WP9S2-27L-350-3K7-4-BC-CLR | 3000 K | 70 CRI | 2426 lm | 77 | 31.6 W | Type 4 | |
| WP9S2-27L-350-3K7-4-BC-CP | 3000 K | 70 CRI | 2205 lm | 70 | 31.6 W | Type 4 | |
| WP9S2-27L-350-3K7-4-BC | 3000 K | 70 CRI | 2753 lm | 87 | 31.6 W | Type 4 | |
| WP9S2-27L-350-3K7-4-CLR | 3000 K | 70 CRI | 3314 lm | 105 | 31.6 W | Type 4 | |
| WP9S2-27L-350-3K7-4-CP | 3000 K | 70 CRI | 3011 lm | 95 | 31.6 W | Type 4 | |
| WP9S2-27L-350-3K7-4 | 3000 K | 70 CRI | 3760 lm | 119 | 31.6 W | Type 4 | |
| WP9S2-27L-350-3K7-4W-BC-CLR | 3000 K | 70 CRI | 2051 lm | 65 | 31.6 W | Type 4W | |
| WP9S2-27L-350-3K7-4W-BC-CP | 3000 K | 70 CRI | 1864 lm | 59 | 31.6 W | Type 4W | |
| WP9S2-27L-350-3K7-4W-BC | 3000 K | 70 CRI | 2327 lm | 74 | 31.6 W | Type 4W | |
| WP9S2-27L-350-3K7-4W-CLR | 3000 K | 70 CRI | 3159 lm | 100 | 31.6 W | Type 4W | |
| WP9S2-27L-350-3K7-4W-CP | 3000 K | 70 CRI | 2871 lm | 91 | 31.6 W | Type 4W | |
| WP9S2-27L-350-3K7-4W | 3000 K | 70 CRI | 3585 lm | 113 | 31.6 W | Type 4W | |
| WP9S2-27L-350-3K7-5Q-CLR | 3000 K | 70 CRI | 3292 lm | 104 | 31.6 W | Type 5Q | |
| WP9S2-27L-350-3K7-5Q-CP | 3000 K | 70 CRI | 2992 lm | 95 | 31.6 W | Type 5Q | |
| WP9S2-27L-350-3K7-5Q | 3000 K | 70 CRI | 3736 lm | 118 | 31.6 W | Type 5Q | |
| WP9S2-27L-350-3K7-L-CLR | 3000 K | 70 CRI | 3147 lm | 100 | 31.6 W | Type L | |
| WP9S2-27L-350-3K7-L-CP | 3000 K | 70 CRI | 2860 lm | 91 | 31.6 W | Type L | |
| WP9S2-27L-350-3K7-L | 3000 K | 70 CRI | 3572 lm | 113 | 31.6 W | Type L | |
| WP9S2-27L-350-3K7-R-CLR | 3000 K | 70 CRI | 3148 lm | 100 | 31.6 W | Type R | |
| WP9S2-27L-350-3K7-R-CP | 3000 K | 70 CRI | 2861 lm | 91 | 31.6 W | Type R | |
| WP9S2-27L-350-3K7-R | 3000 K | 70 CRI | 3572 lm | 113 | 31.6 W | Type R | |
| WP9S2-27L-350-4K7-1-BC-CLR | 4000 K | 70 CRI | 2265 lm | 72 | 31.6 W | Type 1 | |
| WP9S2-27L-350-4K7-1-BC-CP | 4000 K | 70 CRI | 2059 lm | 65 | 31.6 W | Type 1 | |
| WP9S2-27L-350-4K7-1-BC | 4000 K | 70 CRI | 2570 lm | 81 | 31.6 W | Type 1 | |
| WP9S2-27L-350-4K7-1-CLR | 4000 K | 70 CRI | 3472 lm | 110 | 31.6 W | Type 1 | |
| WP9S2-27L-350-4K7-1-CP | 4000 K | 70 CRI | 3155 lm | 100 | 31.6 W | Type 1 |
