EXO
SG Sling Wall

The SG Sling is a slender wallpack/floodlight available in two sizes for a variety of applications.

Features & Benefits

  • Ranges from 21W to 80W with up to 8,000 lumens
  • SG1 Series replaces from 100W-150W HID
  • SG2 Series replaces from 150W-250W HID
  • Four ½” threaded conduit hubs for surface conduit
  • Decorative die-cast aluminum housing
  • Available in five standard colors
Where To Buy
SPEC SHEET

Specifications

Mounting Options
Wall (surface), Knuckle Swivel
Color Offering
BLS - Black Gloss Smooth, BLT - Black Matte Textured, DBS - Dark Bronze Gloss Smooth, DBT- Dark Bronze Matte Textured, GTT - Graphite Matte Textured, LGT - Light Grey Matte Textured, LGS - Light Grey Gloss Smooth, PSS - Platinum Silver Gloss Smooth, VGT - Verde Green Matte Textured, WHS - White Gloss Smooth, WHT - White Matte Textured, CC – Custom Color
Beam Angle
Direct
Certifications
CSAus, CSA, UL 1598
Ratings
IP65, Damp, Wet
Warranty
5 year limited
Material
Diecast Aluminum
Wattage
21-80

Product Documents

Brochures / Catalogs

Color Chart Brochure
806 KB
2024-09-12
SG Sling Brochure
4996 KB
2023-08-03
LED Emergency/Egress Guide
2260 KB
2023-08-03

Design / BIM Files / 3D Models

SG BIM file
1192 KB
2023-08-03

Technical Documents

Warranties

Photometry(0)

Clear Filters

Product Name Color Temp CRI Lumens LM/W Watts Dist. Type Resources
SG2-E_Emergency_Mode70 CRIForward Throw
SG1-20-3K7-FT-Visor3000 K70 CRI2054 lm9521 WForward Throw
SG1-20-4K7-FT-Visor4000 K70 CRI2310 lm11021 WForward Throw
SG1-20-5K7-FT-Visor5000 K70 CRI2449 lm11521 WForward Throw
SG1-30-3K7-FT-Visor3000 K70 CRI2913 lm10029 WForward Throw
SG1-30-4K7-FT-Visor4000 K70 CRI3060 lm10629 WForward Throw
SG1-30-5K7-FT-Visor5000 K70 CRI3332 lm11729 WForward Throw
SG2-50-3K7-FT-Visor3000 K70 CRI4700 lm9251 WForward Throw
SG2-50-4K7-FT-Visor4000 K70 CRI5526 lm10751 WForward Throw
SG2-50-5K7-FT-Visor5000 K70 CRI5548 lm10951 WForward Throw
SG2-80-3K7-FT-Visor3000 K70 CRI6721 lm8680 WForward Throw
SG2-80-4K7-FT-Visor4000 K70 CRI8079 lm10380 WForward Throw
SG2-80-5K7-FT-Visor5000 K70 CRI7851 lm9880 WForward Throw
SG1-20-3K7-FT3000 K70 CRI2054 lm9521 WForward Throw
SG1-20-4K7-FT4000 K70 CRI2310 lm11021 WForward Throw
SG1-20-5K7-FT5000 K70 CRI2449 lm11521 WForward Throw
SG1-30-3K7-FT3000 K70 CRI2913 lm10029 WForward Throw
SG1-30-4K7-FT4000 K70 CRI3060 lm10629 WForward Throw
SG1-30-5K7-FT5000 K70 CRI3332 lm11729 WForward Throw
SG2-50-3K7-FT-UHV3000 K70 CRI3895 lm9044 WForward Throw
SG2-50-3K7-FT3000 K70 CRI4700 lm9251 WForward Throw
SG2-50-4K7-FT-UHV4000 K70 CRI4609 lm10544 WForward Throw
SG2-50-4K7-FT4000 K70 CRI5526 lm10751 WForward Throw
SG2-50-5K7-FT-UHV5000 K70 CRI4633 lm10644 WForward Throw
SG2-50-5K7-FT5000 K70 CRI5548 lm10951 WForward Throw
SG2-80-3K7-FT3000 K70 CRI6721 lm8680 WForward Throw
SG2-80-4K7-FT4000 K70 CRI8079 lm10380 WForward Throw
SG2-80-5K7-FT5000 K70 CRI7851 lm9880 WForward Throw
SG1-40-4K4000 K70 CRI4070 lm10738 WForward Throw
SG1-40-3K3000 K70 CRI3845 lm9938 WForward Throw
SG1-10-5K5000 K70 CRI1349 lm12411 WForward Throw
SG1-10-4K4000 K70 CRI1424 lm12511 WForward Throw
SG1-10-3K3000 K70 CRI1346 lm11811 WForward Throw
SG1-40-5K5000 K70 CRI4008 lm10538 WForward Throw
