EXO
Prelude Wallpacks

PRL-R-LS (refractor) PRL-C-LS (cut off) Prelude Wallpack luminaires feature field selectable Wattages from 18 to 60 Watts.

Features & Benefits

  • Cut off and Refractor form Wall Mounted Stylish Fixture contemporary architectural form provides an updated appearance compared to traditional HID wall packs
  • LED wall luminaire for lighting applications such as retail, commercial and industrial building mount
  • Field Selectable Wattages from 18 to 60 Watts
  • Lumen Range from 2500-8500 lumens
  • Type III Distribution for Full cut off configuration, (PRL-C) for applications requiring no up-light
  • Type IV Distribution for Refractor Form configuration, (PRL-R) provides a further throw and higher angle light
Where To Buy
SPEC SHEET

Specifications

Lumen Range
700 - 8,000
Dimming Protocol
0-10V;10%
CCT Offering
4000
CRI Offering
70
Mounting Options
Wall (surface)
Color Offering
Dark Bronze

Product Documents

Prelude Spec Sheet
510 KB
2022-12-01

Brochures / Catalogs

Prelude Flyer
396 KB
2022-11-04

Sell Sheets

Prelude Wallpack Flyer
396 KB
2022-10-26

Installation Guides

Warranties

Photometry(0)

Clear Filters

Product Name Color Temp CRI Lumens LM/W Watts Dist. Type Resources
PRS-20-5K5000 K70 CRI2840 lm12522.8 WType IV
PRL-R-LS-4K-43W4000 K70 CRI6099 lm142Type 4
PRL-C-LS-4K-18W4000 K70 CRI2537 lm141Type 3
PRL-C-LS-4K-60W4000 K70 CRI8460 lm139Type 3
PRL-C-LS-4K-52W4000 K70 CRI7331 lm141Type 3
PRL-C-LS-4K-26W4000 K70 CRI3665 lm141Type 3
PRL-R-LS-4K-35W4000 K70 CRI4964 lm142Type 4
PRS-20-4K4000 K70 CRI2899 lm9622.8 WType IV
PRL-R-LS-4K-52W4000 K70 CRI7375 lm142Type 4
PRL-R-LS-4K-18W4000 K70 CRI2553 lm142Type 4
PRL-C-LS-4K-43W4000 K70 CRI6062 lm141Type 3
PRL-C-LS-4K-35W4000 K70 CRI4934 lm141Type 3
PRL-R-LS-4K-26W4000 K70 CRI3688 lm142Type 4
PRL-R-LS-4K-60W4000 K70 CRI8510 lm144Type 4
