LITECONTROL
MOD™ 2L LED Wall Indirect/Direct 2L-W-ID

The MODx™ family is an affordably-priced, full-featured offering with best-in-class attention to detail.

Features & Benefits

  • Now available Contractor-Ready for faster and easier installation
  • Variable Intensity technology provides specifiable uplight and downlight light levels
  • End cap design eliminates visible diffuser seams/gaps
  • 2 SDCM color variation
  • LPA distribution available

Specifications

Aperture
2
Product Technology
SpectraSync™ Color Tuning, Vi (Variable Intensity)
Voltage Offering
120-277
Dimming Protocol
0-10V;Lutron EcoSystem Digital;DALI;DALI 2.0;0%;1%;5%;Step-Dimming
CCT Offering
2700, 3000, 3500, 4000, 5000
CRI Offering
80, 90
Color Tuning
Tunable White, Dim-to-Warm
Mounting Options
Wall
Wattage Range
5.4 - 24.9
Efficacy Range
90 - 111
Optics & Distributions
Indirect/Direct
Controls & Sensors
Occupancy, Daylighting, NX Lighting Controls
Certifications
CSA, UL 924
Ratings
BAA (Buy American 52.225-9), TAA (Buy American 52.225-11)
Warranty
5 year limited

Product Documents

1545 KB
2022-11-21

Brochures / Catalogs

18503 KB
2022-10-28
12801 KB
2022-10-25
460 KB
2022-06-20

Sell Sheets

938 KB
2022-11-21
2452 KB
2022-11-21

Design / BIM Files / 3D Models

788 KB
2022-10-10

Installation Guides

Photometry(0)

Clear Filters

Product Name Color Temp CRI Lumens LM/W Watts Dist. Type Resources
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0503500 K80 CRI4800 lm9849 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0653500 K80 CRI4400 lm9945 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0553500 K80 CRI3800 lm9938 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0603500 K80 CRI5400 lm9755 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0403500 K80 CRI4200 lm9843 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0753500 K80 CRI5000 lm9951 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D1003500 K80 CRI7400 lm9578 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0453500 K80 CRI3200 lm9833 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0703500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0303500 K80 CRI3600 lm9837 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0853500 K80 CRI5600 lm9857 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0903500 K80 CRI6800 lm9671 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D1003500 K80 CRI5200 lm9654 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D1003500 K80 CRI4000 lm9542 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0353500 K80 CRI1400 lm9315 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0353500 K80 CRI2600 lm9727 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0803500 K80 CRI6600 lm9669 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0953500 K80 CRI5800 lm9760 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0953500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0803500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0353500 K80 CRI3000 lm9831 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0903500 K80 CRI7200 lm9675 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0853500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0303500 K80 CRI4000 lm9741 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0703500 K80 CRI5600 lm9757 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0453500 K80 CRI3600 lm9936 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0753500 K80 CRI4600 lm9847 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0403500 K80 CRI4600 lm9747 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0603500 K80 CRI5000 lm9851 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0553500 K80 CRI4200 lm10042 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0453500 K80 CRI5400 lm9656 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0653500 K80 CRI4000 lm9841 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0503500 K80 CRI5200 lm9754 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0503500 K80 CRI4400 lm9945 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0653500 K80 CRI4800 lm9949 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0353500 K80 CRI4800 lm9650 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0803500 K80 CRI4400 lm9745 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0803500 K80 CRI3200 lm9733 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0553500 K80 CRI2200 lm9623 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0553500 K80 CRI3400 lm9835 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0603500 K80 CRI5800 lm9760 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0403500 K80 CRI3800 lm9938 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0753500 K80 CRI5400 lm9855 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D1003500 K80 CRI7000 lm9673 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0903500 K80 CRI5000 lm9752 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0703500 K80 CRI6400 lm9667 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0303500 K80 CRI3200 lm9833 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0853500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0903500 K80 CRI6400 lm9766 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D1003500 K80 CRI5600 lm9658 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0953500 K80 CRI5400 lm9756 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0953500 K80 CRI6600 lm9669 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0803500 K80 CRI5800 lm9859 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0353500 K80 CRI3400 lm9934 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0653500 K80 CRI6200 lm9664 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0853500 K80 CRI4800 lm9749 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0303500 K80 CRI4400 lm9646 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0703500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0453500 K80 CRI4000 lm9940 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0553500 K80 CRI5600 lm9758 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0603500 K80 CRI3600 lm9837 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0603500 K80 CRI2400 lm9625 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0753500 K80 CRI3000 lm9731 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0753500 K80 CRI4200 lm9743 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0403500 K80 CRI5000 lm9652 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0603500 K80 CRI4600 lm9946 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0553500 K80 CRI4600 lm9947 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0453500 K80 CRI5000 lm9752 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0703500 K80 CRI4200 lm9843 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0503500 K80 CRI5600 lm9658 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0503500 K80 CRI4000 lm10040 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0653500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0353500 K80 CRI4400 lm9746 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0803500 K80 CRI4800 lm9849 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0403500 K80 CRI3400 lm9934 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0753500 K80 CRI5800 lm9760 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D1003500 K80 CRI6600 lm9669 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0903500 K80 CRI5400 lm9755 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0853500 K80 CRI7000 lm9673 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0303500 K80 CRI2800 lm9729 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0853500 K80 CRI6400 lm9766 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0903500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D1003500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0753500 K80 CRI6400 lm9666 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0403500 K80 CRI2800 lm9729 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0403500 K80 CRI1600 lm9417 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0953500 K80 CRI3800 lm9540 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0953500 K80 CRI5000 lm9652 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0953500 K80 CRI7000 lm9673 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0803500 K80 CRI5400 lm9855 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0353500 K80 CRI3800 lm9839 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0653500 K80 CRI5800 lm9760 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0503500 K80 CRI3400 lm9934 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0303500 K80 CRI4800 lm9551 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0703500 K80 CRI4800 lm9949 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0453500 K80 CRI4400 lm9845 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0553500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0603500 K80 CRI4000 lm9941 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0603500 K80 CRI4200 lm9942 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0553500 K80 CRI5000 lm9851 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0453500 K80 CRI4600 lm9847 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0703500 K80 CRI4600 lm9947 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0503500 K80 CRI3600 lm9936 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0653500 K80 CRI5600 lm9758 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0353500 K80 CRI4000 lm9741 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0803500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0953500 K80 CRI7200 lm9675 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0403500 K80 CRI3000 lm9831 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0753500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D1003500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0903500 K80 CRI5800 lm9759 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0853500 K80 CRI6600 lm9668 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0303500 K80 CRI2600 lm9727 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0303500 K80 CRI1200 lm9213 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0303500 K80 CRI2400 lm9625 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0853500 K80 CRI6800 lm9671 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0903500 K80 CRI5600 lm9857 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D1003500 K80 CRI6400 lm9666 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0753500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0403500 K80 CRI3200 lm9833 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0953500 K80 CRI7400 lm9578 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0803500 K80 CRI5000 lm9851 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0353500 K80 CRI4200 lm9743 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0653500 K80 CRI5400 lm9855 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0503500 K80 CRI3800 lm9938 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0703500 K80 CRI4400 lm9845 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0453500 K80 CRI4800 lm9749 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0553500 K80 CRI4800 lm9849 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0603500 K80 CRI4400 lm9944 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0403500 K80 CRI5200 lm9654 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0603500 K80 CRI3800 lm9839 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0553500 K80 CRI5400 lm9756 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0453500 K80 CRI4200 lm9943 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0703500 K80 CRI5000 lm9951 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0303500 K80 CRI4600 lm9548 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0853500 K80 CRI4600 lm9747 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0853500 K80 CRI3400 lm9735 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0503500 K80 CRI2000 lm9521 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0503500 K80 CRI3200 lm9833 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0653500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0353500 K80 CRI3600 lm9837 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0803500 K80 CRI5600 lm9857 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0953500 K80 CRI6800 lm9671 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0953500 K80 CRI5200 lm9654 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0753500 K80 CRI6600 lm9669 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D1003500 K80 CRI5800 lm9660 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0903500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0853500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0303500 K80 CRI3000 lm9831 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0903500 K80 CRI5200 lm9754 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D1003500 K80 CRI6800 lm9671 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0753500 K80 CRI5600 lm9857 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0403500 K80 CRI3600 lm9936 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0603500 K80 CRI6000 lm9662 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0803500 K80 CRI4600 lm9847 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0353500 K80 CRI4600 lm9648 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0653500 K80 CRI5000 lm9851 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0503500 K80 CRI4200 lm9942 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0503500 K80 CRI5400 lm9756 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0653500 K80 CRI3800 lm9839 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0653500 K80 CRI2600 lm9627 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0703500 K80 CRI2800 lm9729 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0703500 K80 CRI4000 lm9841 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0453500 K80 CRI5200 lm9654 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0553500 K80 CRI4400 lm9944 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0603500 K80 CRI4800 lm9949 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0403500 K80 CRI4800 lm9750 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0753500 K80 CRI4400 lm9845 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0553500 K80 CRI5800 lm9660 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0453500 K80 CRI3800 lm9938 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0703500 K80 CRI5400 lm9855 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0303500 K80 CRI4200 lm9644 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0853500 K80 CRI5000 lm9851 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0353500 K80 CRI3200 lm9833 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0803500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0953500 K80 CRI6400 lm9766 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0953500 K80 CRI5600 lm9758 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0803500 K80 CRI6800 lm9671 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D1003500 K80 CRI5400 lm9656 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0903500 K80 CRI6600 lm9668 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0853500 K80 CRI5800 lm9859 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0303500 K80 CRI3400 lm9835 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0703500 K80 CRI6200 lm9764 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0453500 K80 CRI3000 lm9831 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-D-4-DRP-X-CX-35K-D0453500 K80 CRI1800 lm9519 WDirect: Lambertian
2L-W-D-4-DRP-X-CX-35K-D0903500 K80 CRI3600 lm9538 WDirect: Lambertian
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I030-D0903500 K80 CRI4800 lm9650 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D1003500 K80 CRI7200 lm9675 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0753500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I060-D0403500 K80 CRI4000 lm9841 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0603500 K80 CRI5600 lm9758 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0553500 K80 CRI3600 lm9936 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D0353500 K80 CRI5000 lm9552 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0653500 K80 CRI4600 lm9946 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0503500 K80 CRI4600 lm9847 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0503500 K80 CRI5000 lm9851 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0653500 K80 CRI4200 lm9843 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0553500 K80 CRI4000 lm9940 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0603500 K80 CRI5200 lm9853 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I070-D0403500 K80 CRI4400 lm9745 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I045-D0753500 K80 CRI4800 lm9849 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I090-D1003500 K80 CRI7600 lm9580 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I040-D0453500 K80 CRI3400 lm9934 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I075-D0703500 K80 CRI5800 lm9760 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I065-D0303500 K80 CRI3800 lm9739 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I050-D0853500 K80 CRI5400 lm9855 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I085-D0903500 K80 CRI7000 lm9673 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I035-D0353500 K80 CRI2800 lm9729 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I080-D0803500 K80 CRI6400 lm9766 WIndirect/Direct: Low-Peak Angle/Asymmetric
2L-W-IAD-LPA-4-ASYM-IND-CX-35K-I055-D0953500 K80 CRI6000 lm9762 WIndirect/Direct: Low-Peak Angle/Asymmetric
Show All

Related Products

LOOKING TO PURCHASE?

Find an Agent


TALK TO AN EXPERT

Contact us
