BEACON
Factor FSL Floodlight

Ultra compact LED high performance architectural styled energy-efficient floodlights feature multiple NEMA beam spreads.

Features & Benefits

IP66, listed to UL1598 for use in wet locations
Vented housing design isolates LED module from driver for long life and improved performance
NEMA distributions Narrow (3x3), Medium (4x4), Rectangular Medium (5x4) and Wide (6x6)
Seven standard finishes: Dark Bronze, Black, Gray, White, Platinum, Red and Forest Green
Photocontrol available for energy savings
Visor and vandal lens accessories available

Where To Buy

SPEC SHEET

Specifications

Dimming Protocol

0-10V;10%

Color Offering

Black Matte Textured, Black Gloss Smooth, Dark Bronze Matte Textured, Dark Bronze Gloss Smooth, Graphite Matte Textured, Light Grey Gloss Smooth, Platinum Silver Smooth, White Matte Textured, White Gloss Smooth, Verde Green Textured

Controls & Sensors

Photocontrol

Specifications

Dimming Protocol	0-10V;10%
Color Offering	Black Matte Textured, Black Gloss Smooth, Dark Bronze Matte Textured, Dark Bronze Gloss Smooth, Graphite Matte Textured, Light Grey Gloss Smooth, Platinum Silver Smooth, White Matte Textured, White Gloss Smooth, Verde Green Textured
Controls & Sensors	Photocontrol

Product Documents

Spec Sheets

Factor FSL specification sheet

434 KB

2023-02-24

Brochures / Catalogs

Color Chart Brochure

2404 KB

2023-02-03

Factor Series Brochure

2083 KB

2022-11-04

Design / BIM Files / 3D Models

FSL BIM file

900 KB

2022-10-10

Installation Guides

FML instruction sheet

317 KB

2022-09-09

Warranties

Commercial and Industrial Outdoor Lighting

221 KB

2022-08-30

Photometry(0)

Clear Filters

Product Name	Color Temp	CRI	Lumens	LM/W	Watts	Dist. Type	Resources
FSL-10L-25-3K8-W-U-X-XX	3000 K	80 CRI	1984 lm	83	25 W	6x6	IES File Quick Design Tool
FSL-7L4K	4000 K	70 CRI	2406 lm	93	25 W	6x6	IES File Quick Design Tool
FSL-10L-25-5K7-M-U-X-XX	5000 K	70 CRI	2742 lm	109	25 W	4x4	IES File Quick Design Tool
FSL-10L-25-4K7-W-U-X-XX	4000 K	70 CRI	2463 lm	98.5	25 W	6x6	IES File Quick Design Tool
FSL-10L-25-4K7-M-U-X-XX	4000 K	70 CRI	2511 lm	105	25 W	4x4	IES File Quick Design Tool
FSL-10L-25-5K7-W-U-X-XX	5000 K	70 CRI	2664 lm	106.5	25 W	6x6	IES File Quick Design Tool
FSL-10L-25-3K8-M-U-X-XX	3000 K	80 CRI	2008 lm	84	25 W	4x4	IES File Quick Design Tool
FSL-10L-25-3K8-RM-U-X-XX	3000 K	80 CRI	1714 lm	71	25 W	5x4	IES File Quick Design Tool
FSL-10L-25-5K7-N-U-X-XX	5000 K	70 CRI	2735 lm	110	25 W	3x3	IES File Quick Design Tool
FSL-10L-25-4K7-RM-U-X-XX	4000 K	70 CRI	2124 lm	89	25 W	5x4	IES File Quick Design Tool
FSL-10L-25-4K7-N-U-X-XX	4000 K	70 CRI	2583 lm	108	25 W	3x3	IES File Quick Design Tool
FSL-10L-25-5K7-RM-U-X-XX	5000 K	70 CRI	2250 lm	88	25 W	5x4	IES File Quick Design Tool
FSL-10L-25-3K8-N-U-X-XX	3000 K	80 CRI	2007 lm	84	25 W	3x3	IES File Quick Design Tool
FSL7	5100 K	70 CRI	2040 lm	77	25 W	6x6	IES File Quick Design Tool
